BAL 25076 Slide Out Gear Box
A BAL replacement gear box for a 12 Volt Accu-Slide Cable Driven Room System.
- Item #
- 90678
- Special Order Item
- No
- Ships LTL Freight
- No
5+ In Stock
$140.42
Description / BAL 25076 Slide Out Gear Box
The BAL 25076 slide out gear box replacement is a replacement gearbox for an R25076 12-volt Accu-Slide cable-driven room system. It is compatible with motor part number R25074, R25075, R25076. The gear box has 13 gear teeth and comes with a mounting bracket installed for easier installation. The box dimensions are 4-3/4" x 2-7/16" x 1-9/16" and the bracket dimensions are 6-1/2" x 2-3/8" x 2-1/2".
More Information
| Item # | 90678 |
|---|---|
| Condition | New |
| Brand | BAL |
| Model | R25076-1 |
| Replaces | R25076 |
| Fits | Accu-Slide Cable Driven Room System, replaces the R25076 gearbox without bracket. If the gearbox will not fit in your application with the bracket installed you may have to remove the bracket. This Gearbox can be used with both Motor Part #'s R25074 or R25075 |
| Included | (1) Gear Box (1) Bracket |
| Dimensions | Box: 4-3/4" x 2-7/16" x 1-9/16" Gear: 13 Teeth Bracket: 6-1/2" x 2-3/8" x 2-1/2" |
| Warranty | Limited 90 Day |
| Net Weight | 4.10 |
| Gross Weight | 4.10 |
| Special Order Item | No |
| LTL Freight | No |
Loading...
Customer Reviews
Quality
5
Price
5
Value
5
Exactly what I needed
Review by
Nobird
I received the gearbox in 4 days. What a fast turn around time. It allowed me to replace the broken one the same week. It was an exact fit to the original one. I replaced the side slide in my 2015 class A. I will purchase another for a spare just to have in case one of the other fall.
Price
5
Value
5
Quality
5
Slide out gear box review
Review by
NV RVer
Bought this replacement gearbox to replace the one in our 2015 5th wheel for the second time. Fair price, quick delivery and product arrived in perfect condition. New housing is slightly different but came with a new bracket so no problem. Bolted right up. I would use Dyers again.
Price
5
Value
5
Quality
5
Yamaha 1000
Review by
mike
so far i like it better than my honda. i really like being able to turn off the gas to the carb and it has a drain to empty the carb. i ran it dry and could still drain gas from the carb.
;i ran it for over 5 hours on my rv to see how it runs very slow unit you turn something on. it did not speed up untill the lights and two fans were turn on and still only ran a half speed.
;i ran it for over 5 hours on my rv to see how it runs very slow unit you turn something on. it did not speed up untill the lights and two fans were turn on and still only ran a half speed.
Quality
5
Price
5
Value
5
Slideout gearbox
Review by
John J.
Initial contact with service rep was awesome, product arrived early and did the install myself, no modifications needed to the bracket and it works perfectly. Thanks
Price
5
Value
5
Quality
4
Gearbox
Review by
Dhuhn
Received product for broken gear box,was exact replacement, works great.
Price
4
Value
1
Quality
4
Accuslide gearbox
Review by
Randall
I ordered this as a spare due to the frequent failure of these units but I could not believe how quickly that I received it! It is the exact part that I needed. I will check with DRYERS before I order from anywhere else.
Thank you DRYERS!
Thank you DRYERS!
Price
4
Value
5
Quality
5
Gear box
Review by
Mike
I ordered this item on a Saturday and received it the Tuesday after. Prompt response to my order. Item has been installed and works like it should.
Quality
4
Price
5
Value
5
good buy
Review by
dpalyu
Product works perfectly after modification of mounting bracket. The case is a slightly different design even though the part number is the same.
Quality
4
Price
5
Value
5
R25076 slide out gear box
Review by
Randy Shepherd
The gear box was the correct unit and same number however the new housing has a sholder on the top case half just under the drive gear that will not allow you to mount it up correctly, you will have two options... one is to order the mount bracket with the new gear box or option two... which I did, take a 4 inch angle grinder and grind out the radius on the mount bracket to accept the new gear box, after doing that it mounted just fine and worked as it should....
Quality
5
Price
5
Value
5
great service great value
Review by
matt
No problems, ordered, delivered exactly like as promised. Gear box fit perfect, will order again from Dyers I'm sure.
Price
5
Value
5
Quality
5
Slide Gearbox
Review by
EarlElaineB
Order a new gearbox to have one as a spare. I'm guessing I will have a failed gearbox while on the road. It might be easy to get a mobile tech to fix but really need to have the part on hand just in case the mobile tech doesn't have on in stock.
Quality
5
Price
5
Value
5
Great Buy
Review by
LCAN
Delivered on time. Great price. Fit perfectly.
Quality
5
Price
4
Value
4
Gear boc
Review by
Dan65
Seems to be better made than previous model. Had to reshape mounting brace as new box has a raised ring around surface near gear but Working well .
Price
4
Value
4
Quality
5
Good
Review by
It's a good product
Looks well constive , works good so I bought me a spare !
Price
5
Value
5
Quality
5
Happy Customer
Review by
Dawn M
Exactly what we needed and works perfectly. Arrived quickly and we were back to camping. Thank you!
Price
5
Value
5
Quality
4
Good Purchase
Review by
sracing
Exact replacement, works fine, much better price than RV house. Shipped immediately.
Quality
5
Price
5
Value
5
Room slide gearbox
Review by
Viking Ken
Received a spare gearbox for our slide. Exact replacement in case the OEM gearbox fails while far out in Alaska. Half the price from the manufacturer. Quick delivery too. Thanks!
Price
4
Value
4
Quality
5
Gearbox
Review by
Nick
gearbox was very easy to install. works great.
the staff at Dyers were very helpful. I would definitely recommend them and there service. will use them in the future.
Price
4
Value
5
Quality
5
Fantastic response!!
Review by
Tom S.
Item arrived on time in great condition.
